Concrete Attachment

Name: Concrete Attachment
Brand: BNA

Concrete Attachment is a forklift attachment manufactured with BNA’s 25 years of production experience. Each unit is built to suit your forklift model and capacity; contact us for detailed technical information and a quotation.

Quotation Form

Fill in the form and our team will get back to you with a quotation as soon as possible.

Call Us WhatsApp

Technical Specifications

CONCRETE ATTACHMENT

PRODUCT CODE	CAPACITY Q · kg	LOAD CENTER LC · mm	MOUNTING CLASS ISO · 2328	ROLL DIAMETER A1 - A2 · mm	CHASIS WIDTH WC · mm	ARM LENGTH LA · mm	LOST LOAD INSTANCE E · mm	C.o.G. C · mm	WEIGHT M · kg
CPA3AQ20-20.100	2000	650	3A/4A	200 - 500	900	1300	188	490	720
CPA3AQ20-20.101	2000	650	3A/4A	400 - 800	900	1300	188	490	720
CPA3AQ20-20.102	2000	650	3A/4A	800 - 1200	900	1300	188	490	720

1 hydraulic function.
It is used in loading-unloading and stacking of building materials such as concrete blocks.
It can load the concrete sleeves stacked horizontally onto the transport vehicles vertically.
